Ready-to-deploy and Advanced Programmable IIoT Gateways
Moxa's IIoT gateways are intelligent, secure, reliable, and user-friendly gateways that can help seamlessly translate data into actionable insights. Our entry-level IIoT gateways offer a straightforward means of integrating Modbus devices with Azure, AWS, and MQTT-based cloud platforms. Going beyond this, our advanced IIoT gateways, equipped with programmable features, offer adaptable customized solutions tailored to meet specific needs of diverse industrial applications.
Reliable Connectivity, Boundless Potential
Moxa’s AIG family includes cost-effective as well as high-performance programmable IIoT gateways that fulfil the needs of smart-manufacturing and factory-automation applications.
| Moxa Solutions |
AIG-101 SeriesCost-effective IIoT gateways with built-in data preprocessing
|
AIG-301 SeriesAdvanced IIoT gateways that can be programmed
|
AIG-501 SeriesHigh-performance IIoT gateways for complex data handling
|
|---|---|---|---|
| Connectivity | |||
| Telemetry Message | Azure IoT Device, AWS IoT Core, MQTT Client | Azure IoT Device, Azure IoT Edge, AWS IoT Core, MQTT Client, Sparkplug B | Azure IoT Device, Azure IoT Edge, AWS IoT Core, MQTT Client, Sparkplug B |
| Azure IoT Edge |  |
 |
|
| OPC UA Server | |
|
|
| Modbus RTU/TCP Master/Client | RTU/ASCII/TCP | RTU/ASCII/TCP | RTU/ASCII/TCP |
| Modbus TCP Server (Slave) | |
|
|
| Number of tags supported | 1,500 | 2,048 | 2,048 |
| Moxa Device Integration | ioLogik E1200, UPort 1100/1200 | |
|
| Interface | Ethernet x2 Serial x2 |
Ethernet x2 Serial x2 DIs x4 DOs x4 |
Ethernet x4 Serial x4 DIs x4 DOs x4 |
| Cellular Carrier Approvals | |
|
|
| Device Management | |||
| Cloud Device Management Integration | Azure: Direct Methods AWS: Job MQTT: Remote API Invocations |
Azure: Device/Module Twins, Direct Methods, DPS AWS: Shadow, Job MQTT: Remote API Invocations |
Azure: Device/Module Twins, Direct Methods, DPS AWS: Shadow, Job MQTT: Remote API Invocations |
| Moxa DLM | |
|
|
| OTA Upgrade | |
|
|
| Edge Computing | |||
| Processor | Arm Cortex-A8, 1 GHz, 1 GB RAM, 8 GB eMMC | Armv7, dual-core, 1 GHz, 2 GB RAM, 16 GB eMMC | Intel Atom® E3845, 4 GB RAM, 32 GB CFast |
| Zero-code Data Preprocessing | |
|
|
| IoT Edge Module/ Function Management | |
|
|
| Cybersecurity | |||
| TPM/Secure Boot/ Disk Encryption | |
|
|
| HTTPS | |
|
|
| Role-based Account Management | |
|
|
| Rugged Design | |||
| Wide Temperature Range | |
|
|
| Hazardous Locations | |
|
|
