Simplicity Is the New Smart

Convert multiple protocols effortlessly with a single gateway

Effortlessly Convert Industrial Protocols


The demand for protocol conversions within a single network has increased tremendously because industrial communication systems are getting more and more complex. Moxa's MGate series of protocol gateways offers a variety of industrial protocol conversions and intuitive graphical interfaces to make them easy for you.


Selection Guide for Connecting to a Modbus TCP-based System

Find the gateway based on the protocol your serial-based devices use


MGate Protocol Gateways Choose the protocol your serial-based devices use
Modbus RTU/ASCII Slave Modbus RTU/ASCII Master PROFIBUS Slave PROFIBUS Master J1939 DNP3 Serial Outstation DNP3 Serial Master IEC
60870-5-101
Slave		 IEC
60870-5-101
Master
Modbus TCP-based Systems Modbus TCP Server 5105 MB3000 5101 5111 5118 - 5109 - 5114
Modbus TCP Client MB3000 5105 5101 5111 5118 5109 5109 5114 -
*MB3000: MB3180/MB3280/MB3480, MB3170/MB3270, MB3660

Find the gateway based on the protocol your Ethernet-based devices use


MGate Protocol Gateways Choose the protocol your Ethernet-based devices use
Modbus TCP Client EtherNet/IP Adapter EtherNet/IP Scanner PROFINET Controller DNP3 TCP Outstation DNP3 TCP Client IEC
60870-5-104
Server		 IEC
60870-5-104
Client		 MQTT Broker
Modbus TCP-based Systems Modbus TCP Server - 5105 5105 5103 - 5109 - 5114 5105
Modbus TCP Client 5109 5105 5105 5103 5109 5109 5114 - -
Selection Guide for Connecting to an EtherNet/IP-based System

Find the gateway based on the protocol your serial-based devices use


MGate Protocol Gateways Choose the protocol your serial-based devices use
Modbus RTU/ASCII Slave Modbus RTU/ASCII Master PROFIBUS Master J1939 DF1
EtherNet/IP-based Systems EtherNet/IP
Adapter
 5105 5105 - 5118 EIP3170/3270
EtherNet/IP Scanner 5105 5105 5111 5118 EIP3170/3270

Find the gateway based on the protocol your Ethernet-based devices use


MGate Protocol Gateways Choose the protocol your Ethernet-based devices use
Modbus TCP Server Modbus TCP Client PROFINET Controller MQTT Broker
EtherNet/IP-based Systems EtherNet/IP
Adapter
 5105 5105 - 5105
EtherNet/IP Scanner 5105 5105 5103 -
Selection Guide for Connecting to a PROFINET-based System

Find the gateway based on the protocol your serial-based devices use


MGate Protocol Gateways Choose the protocol your serial-based devices use
Modbus RTU/ASCII Slave Modbus RTU/ASCII Master PROFIBUS Slave PROFIBUS Master J1939
PROFINET-based Systems PROFINET Controller 5103 5103 5102 5111 5118

Find the gateway based on the protocol your Ethernet-based devices use


MGate Protocol Gateways Choose the protocol your Ethernet-based devices use
Modbus TCP Server Modbus TCP Client EtherNet/IP Scanner
PROFINET-based Systems PROFINET Controller 5103 5103 5103

Simply Select the Right Protocol Gateway

To integrate heterogeneous systems, identifying the communication protocols and the relationship between two entities (e.g., master-slave, scanner-adapter, etc.) is essential when it comes to choosing a protocol gateway.

  • Find the right gateway that converts the protocol between your devices and a Modbus TCP-based system.

    Learn More

  • Find the right gateway that converts the protocol between your devices and an EtherNet/IP-based system.

    Learn More

  • Find the right gateway that converts the protocol between your devices and a PROFINET-based system.

    Learn More

Easily Configure Various Protocol Gateways

Our MGate products all feature intuitive user interfaces to enable fast and easy protocol communications. Watch our videos to see how it is easily done for multiple combinations of protocol conversions.


  • Convert Modbus RTU to Modbus TCP in 60 seconds


  • Convert Modbus RTU to EtherNet/IP in 4 steps


  • Convert Modbus RTU to PROFINET in 4 steps
