SDS-3010-2GTXSFP(-T) models: 8
SDS-3010-8PoE-2GTXSFP(-T) models: 8 PoEモデル使用は暫定的です。
Auto negotiation speed
Full/Half duplex mode
Auto MDI/MDI-X connection

SDS-3010-2GTXSFP(-T) models: 2
SDS-3010-8PoE-2GTXSFP(-T) models: 2 PoEモデル使用は暫定的です。

SDS-3010-8PoE-2GTXSFP(-T) models: 8 PoEモデル使用は暫定的です。

IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X)
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3x for flow control
IEEE 802.1D-2004 for Spanning Tree Protocol
IEEE 802.1w for Rapid Spanning Tree Protocol
IEEE 802.1Q for VLAN Tagging
IEEE 802.1p for Class of Service

EtherNet/IP
Modbus TCP
PROFINET IO Device

Back Pressure Flow Control
DHCP Client
Fiber check
Flow control
IPv4/IPv6
LLDP
Port Mirror
RMON
SNMP Inform
SNMPv1/v2c/v3
Syslog

RFC1213
Ethernet-like MIB
IF MIB
LLDP MIB
Bridge MIB
Q-BRIDGE MIB

RSTP
STP
MRP

Broadcast storm protection
HTTPS/SSL
Port Lock
SNMPv3
Trust access control

NTP Server/Client
SNTP

802.1Q VLAN

Read more

8 K

8

VID 1 to 4094

3 Mbits

PWR1, PWR2, STATE, FAULT, 10/100M (TP Port), 10/100/1000M (Gigabit Combo port), smart PoE LED (SDS-3010-8PoE-2GTXSFP(-T) models only) PoEモデル使用は暫定的です。

USB Type A (for ABC-02 only)

1
Relay output with current carrying capacity of 1 A @ 24 VDC

Reset button

1

+13 to +30 V for state 1
-30 to +3 V for state 0
Max. input current: 8 mA

2 removable 4-contact terminal block(s)

SDS-3010-2GTXSFP(-T) models: 12-48 VDC
SDS-3010-8PoE-2GTXSFP(-T) models: 48 VDC PoEモデル使用は暫定的です。
Redundant dual inputs

SDS-3010-2GTXSFP(-T) models: 9.6 to 60 VDC
SDS-3010-8PoE-2GTXSFP(-T) models: 44 to 57 VDC PoEモデル使用は暫定的です。

SDS-3010-2GTXSFP(-T) models: 0.98 A max. 12-48 VDC
SDS-3010-8PoE-2GTXSFP(-T) models: 0.28 A max. 48 VDC PoEモデル使用は暫定的です。

Max. 240 W for total PD consumption @ 48 VDC input
Max. 36 W for each PoE port

Note: PoE model specifications are preliminary.

SDS-3010-2GTXSFP(-T) models: 7.20 W
SDS-3010-8PoE-2GTXSFP(-T) models: 10.76 W full loading without PDs’ consumption PoEモデル使用は暫定的です。

Supported

Supported

Metal

IP40

36 x 135 x 111 mm (1.42 x 5.32 x 4.37 in)

SDS-3010-2GTXSFP(-T): 767g (1.69 lbs)
SDS-3010-8PoE-2GTXSFP(-T): 795g (1.75 lbs) PoEモデル使用は暫定的です。

DIN-rail mounting
Wall mounting (with optional kit)

Standard Models: -10 to 60°C (14 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

EN 55032/35
EN 61000-6-2/-6-4

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 800 MHz: 10 V/m; 800 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV (1.2/50 μs), 1 kV (10/700 μs)
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8 PFMF

EN IEC 62368-1
UL 61010-2-201

IEC 60068-2-27

IEC 60068-2-32

IEC 60068-2-6

SDS-3010-2GTXSFP(-T): 3,086,399 hrs
SDS-3010-8PoE-2GTXSFP(-T): 2,150,066 hrs PoEモデル使用は暫定的です。

Telcordia (Bellcore), GB

5 years

See www.moxa.com/jp/warranty
