IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X)
IEEE 802.3x for flow control

Full/Half duplex mode
Auto MDI/MDI-X connection
Auto negotiation speed

Store and Forward

2 K

512 kbits

12 to 48 VDC

0.12 A @ 24 VDC

1 removable 3-contact terminal block(s)

1.1 A @ 24 VDC

Supported

Plastic

IP30

24.9 x 100 x 86.5 mm (0.98 x 3.94 x 3.41 in)

135 g (0.30 lb)

DIN-rail mounting

-10 to 60°C (14 to 140°F)

-40 to 85°C (-40 to 185°F)

5 to 95% (non-condensing)

UL 508
EN 62368-1

EN 55032/35

CISPR 32, FCC Part 15B Class A

IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV
IEC 61000-4-5 Surge: Power: 1 kV; Signal: 1 kV
IEC 61000-4-6 CS: 3 V
IEC 61000-4-8 PFMF

IEC 60068-2-27

IEC 60068-2-6

IEC 60068-2-32

3,915,945 hrs

Telcordia (Bellcore), GB

5 years

See www.moxa.com/tw/warranty
